Porsche 718 Boxster 982 (2016-2024) switch folding Wiring diagram
This page shows the only wiring diagram for the component.switch folding, which is found in the car Porsche 718 Boxster 982 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch folding (1 of 1)
AREA LIGHTING
BLK WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BUTTON 1, 2 OFF
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
CTRL SWITCH MEMORY SAVE
DISPLAY
DRIVER'S DOOR BUTTON MODULE
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR MEMORY BUTTON MODULE
FOLDING MIRROR POSITION 1
FOLDING MIRROR POSITION 2
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER DOOR MEMORY BUTTON MODULE
FUN DISPLAY ON
FUNCTION DISPLAY ON FUNCTION IND OFF
FUSE 6
FUSE 7
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/WHT WIRE
HEATING
HOT AT ALL TIMES
IND OFF
LED MEM OFF
LED MEM SET
LED MEMORY OFF
LED MEMORY SET
LEFT COURTESY LIGHTS MIRROR
LEFT DOOR MIRROR HEATING
LEFT FRONT FUSE BOX (ROW C)
LEFT MEMORY EXTERIOR MIRRORS SERVO MOTOR
LEFT MIRROR FOLDING MOTOR
LH CTRL UNIT MIRROR
LH MIRROR FUNCTION
MEM CTRL SWITCH
MEM OFF BUTTON
MIRROR ADJUSTMENT
MIRROR ADJUSTMENT CTRL SWITCH
MIRROR ADJUSTMENT MOTOR X
MIRROR ADJUSTMENT MOTOR Y
MIRROR CHANGEOVER
MIRROR COURTESY LIGHT
MIRROR MOTOR SPLY
MIRROR MOTOR SPLY MIRROR ADJUSTMENT MOTOR X
MIRROR SEL CTRL SWITCH
MIRROR TERM 31
MOTOR 1
MOTOR 1/2
MOTOR 2
ORG/BRN WIRE
ORG/GRN WIRE
POTENTIOMETER
POTENTIOMETER SPLY
POTI ENGINE 1
POTI ENGINE 2
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RH CTRL UNIT MIRROR
RH MIRROR FUNCTION
RIGHT COURTESY LIGHTS MIRROR
RIGHT DOOR MIRROR HEATING
RIGHT FRONT FUSE BOX (ROW C)
RIGHT MEMORY EXTERIOR MIRRORS SERVO MOTOR
RIGHT MIRROR FOLDING MOTOR
SET BUTTON
STATUS POS X
STATUS POS Y
SWITCH FOLDING
TERM 30
TERM 31
VIO WIRE
VIO/GRY WIRE
VIO/RED WIRE
VIO/YEL WIRE
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Memory mirrors circuit -> SWITCH FOLDING
