Porsche 718 Boxster 982 (2016-2024) spoiler hall sensor Wiring diagram
This page shows the only wiring diagram for the component.spoiler hall sensor, which is found in the car Porsche 718 Boxster 982 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spoiler hall sensor (1 of 1)
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
COOLANT LEVEL SWITCH
EXTEND MTR +
FUSE 4
HALL SENS
HALL SENS 1 -
HALL SENS 2
HOT AT ALL TIMES
LEFT FRONT FUSE BOX (ROW B)
ORG/BRN WIRE
ORG/GRN WIRE
REAR BCM (UNDER DRIVER'S SEAT)
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/WHT WIRE
RETRACT MTR +
SENS GND
SPOILER HALL SENSOR
TERM 30 1
TERM 31
VIO WIRE
VIO/BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
Go to component -> Active bodyworks circuit -> SPOILER HALL SENSOR
