Porsche 718 Boxster 982 (2016-2024) left pwr window button ctrl sw Wiring diagram
This page shows the only wiring diagram for the component.left pwr window button ctrl sw, which is found in the car Porsche 718 Boxster 982 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left pwr window button ctrl sw (1 of 1)
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN HIGH
CAN LOW
CLOSE MOTOR 1
CLOSE MOTOR 2
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR BUTTON MODULE
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR POWER WINDOW MOTOR
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER DOOR POWER WINDOW BUTTON
FRONT PASSENGER DOOR POWER WINDOW MOTOR
FUSE 6
FUSE 7
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT FUSE BOX (ROW C)
LEFT PWR WINDOW BUTTON CTRL SW
MOTOR 1
MOTOR 2
OPEN MOTOR 1
ORG/BRN WIRE
ORG/GRN WIRE
PWR WINDOW BUTTON LOCAL CTRL SW
RED WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FUSE BOX (ROW C)
RIGHT PWR WINDOW BUTTON CTRL SW
TERM 30
TERM 31
TERM 31 CTRL SW
VIO WIRE
WINDOW CODED
WINDOW LEFT
WINDOW RIGHT
Go to component -> Power windows circuit -> LEFT PWR WINDOW BUTTON CTRL SW
