Porsche 718 Boxster 982 (2016-2024) backrest forward Wiring diagrams
This page contains all the electrical diagrams for the component. backrest forward, in which he is found in the car Porsche 718 Boxster 982 (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram backrest forward (1 of 2)
BACKREST BACK
BACKREST FORWARD
BRN WIRE
DRIVER STANDARD 2-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
DRIVER STANDARD 4-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR
DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR
FUSE 3
GRY/BLK WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT FRONT FUSE BOX (ROW A)
LOWER SEAT
POWER DISTRIBUTION SYSTEM
RAISE SEAT
RED WIRE
RED/BLK WIRE
TERM 30
TERM 31
TERM 31 BACK BACKREST ADJUSTMENT BACKREST FORWARD ADJUSTMENT
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Driver power seat circuit -> BACKREST FORWARD
Wiring diagram backrest forward (2 of 2)
BACK BACKREST ADJUSTMENT
BACKREST BACK
BACKREST FORWARD
BRN WIRE
FORWARD BACKREST ADJUSTMENT
FRONT PASSENGER STANDARD 2-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER STANDARD 4-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER'S SEAT BACKREST ADJUSTMENT MOTOR
FUSE 4
GRY/BLK WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LOWER SEAT
PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR
POWER DISTRIBUTION SYSTEM
RAISE SEAT
RED WIRE
RIGHT FRONT FUSE BOX (ROW A)
TERM 30
TERM 31
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Passenger power seat circuit -> BACKREST FORWARD
