Porsche 718 Boxster 982 (2016-2024) back backrest adjustment Wiring diagram
This page shows the only wiring diagram for the component.back backrest adjustment, which is found in the car Porsche 718 Boxster 982 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back backrest adjustment (1 of 1)
BACK BACKREST ADJUSTMENT
BACKREST BACK
BACKREST FORWARD
BRN WIRE
FORWARD BACKREST ADJUSTMENT
FRONT PASSENGER STANDARD 2-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER STANDARD 4-WAY SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER'S SEAT BACKREST ADJUSTMENT MOTOR
FUSE 4
GRY/BLK WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LOWER SEAT
PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR
POWER DISTRIBUTION SYSTEM
RAISE SEAT
RED WIRE
RIGHT FRONT FUSE BOX (ROW A)
TERM 30
TERM 31
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Passenger power seat circuit -> BACK BACKREST ADJUSTMENT
