Car Wiring Diagrams for 2.4l vin 0, a/t circuit, 5 speed a/t for Pontiac Vibe II (2008-2010)

54 56 PNP SW NEUTRAL SIG PNP SW DRIVE SIG PNK WIRE 73 53 PNP SWITCH PARK SIG BACKUP LAMP SW SIG 9 7 PNK WIRE AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR AUTOMATIC TRANSMISSION SHIFT LEVER BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE ECU-IG 1 FUSE 6 ECU-IG 2 FUSE 7 ETCS FUSE GRY WIRE HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) HOT W/ IGN 1 RELAY ENERGIZED I/P FUSE BLOCK (LEFT END OF DASH) LT BLU WIRE LT GRN WIRE ORG/ WIRE PARK/NEUTRAL POSITION (PNP) SWITCH (ON TRANSMISSION) PNK WIRE PNK/DK GRN WIRE PNP SWITCH LOW SIG POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT) RED WIRE S-D SHIFT SHIFT SOLENOID SOLENOID VALVE VALVE (SSV) DSL SHIFT SOLENOID VALVE SHIFT SOLENOID VALVE (SSV) SLT SHIFT SOLENOID VALVE (SSV) SR SLT LOW CONTROL SLT HIGH CONTROL SLT HIGH CONTROL TRANSMISSION CONNECTOR VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
