Car Wiring Diagrams for 2.4l vin 0, a/t circuit, 4 speed a/t for Pontiac Vibe II (2008-2010)

73 53 54 PNP SWITCH PARK SIG BACKUP LAMP SW SIG PNP SW NEUTRAL SIG AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR AUTOMATIC TRANSMISSION INPUT SHAFT SPEED (ISS) SENSOR (ON TRANSMISSION) AUTOMATIC TRANSMISSION OUTPUT SHAFT SPEED (OSS) SENSOR (ON TRANSMISSION) AUTOMATIC TRANSMISSION SHIFT LEVER BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE ECU-IG 2 FUSE 7 GRY WIRE HOT AT ALL TIMES UNDERHOOD FUSE BLOCK ETCS FUSE (LEFT SIDE OF ENGINE COMPT) HOT W/ IGN 1 RELAY ENERGIZED I/P FUSE BLOCK (LEFT END OF DASH) LT GRN WIRE ORG/ WIRE PARK/NEUTRAL POSITION (PNP) SWITCH (ON TRANSMISSION) PNK 3 8 WIRE PNK 56 55 74 PNP SW DRIVE SIG PNP SW SECOND SIG PNP SWITCH LOW SIG WIRE PNK WIRE PNK/DK GRN WIRE POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT) RED WIRE SHIFT SOLENOID VALVE SLT LOW CONTROL SLT HIGH CONTROL SHIFT SOL VLV DSL CTRL TRANSMISSION CONNECTOR VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
