1.8l vin 8, a/t circuit for Pontiac Vibe II (2008-2010)
1.8l vin 8, a/t circuit
73 53 54 PNP SWITCH PARK SIG BACKUP LAMP SW SIG PNP SW NEUTRAL SIG
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
AUTOMATIC TRANSMISSION INPUT SHAFT SPEED (ISS) SENSOR (ON TRANSMISSION)
AUTOMATIC TRANSMISSION SHIFT LEVER POSITION INDICATOR
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
ECU-IG 2 FUSE 7
GRY WIRE
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK ETCS FUSE (LEFT SIDE OF ENGINE COMPT)
HOT W/ IGN 1 RELAY ENERGIZED
I/P FUSE BLOCK (LEFT END OF DASH)
LOW SIGNAL HIGH SIGNAL
LT GRN WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (ON TRANSMISSION)
PNK 56 55 74 PNP SW DRIVE SIG PNP SW SECOND SIG PNP SWITCH LOW SIG WIRE
PNK WIRE
PNK/DK GRN WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT)
RED WIRE
SHIFT SHIFT SOLENOID SOLENOID VALVE VALVE (SSV) ST
SHIFT SOLENOID VALVE
SHIFT SOLENOID VALVE (SSV) SLT
SHIFT SOLENOID VALVE (SSV) SLU
TRANSMISSION CONNECTOR
VIO WIRE
WHT WIRE
YEL WIRE
