Pontiac Vibe II (2008-2010) Charging circuit

1.8L 2.4L BATTERY BLK WIRE CHARGE IND DAYTIME RUNNING LIGHTS (DRL) MODULE (LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE ECU-IG FUSE 7 FUSIBLE LINK (12 GA- GENERATOR HVAC CONTROL MODULE (CENTER OF DASH) I/P FUSE BLOCK (LEFT END OF DASH) INSTRUMENT PANEL CLUSTER (IPC) LOGIC METER FUSE 31 POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF ENGINE COMPT) RELAY ENERGIZED STARTER UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) ALT FUSE ALT S FUSE WHT WIRE YEL WIRE
