Anti-lock brakes circuit for Pontiac Vibe II (2008-2010)

Anti-lock brakes circuit (1 of 2)

Get access

BATTERY POSITIVE VOLT SERIAL DATA BUS+ BLK WIRE BODY CONTROL MODULE BRN WIRE BUS - COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/BLK WIRE DK BLU/WHT WIRE DK GRN WIRE ECU-B ABS 1 FUSE FUSE ECU-IG 1 FUSE 6 ELECTRONIC BRAKE CONTROL MODULE (EBCM) (RIGHT SIDE OF ENGINE COMPARTMENT) GRY WIRE HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED I/P FUSE BLOCK (LEFT END OF DASH) LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT WHEEL HUB ASSEMBLY) LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, LEFT REAR WHEEL SPEED SENSOR (LEFT REAR WHEEL HUB ASSEMBLY) LT BLU WIRE LT GRN WIRE PNK VEH STABILITY CTRL SW IN WIRE PNK WIRE RED WIRE RED/BLK WIRE RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT WHEEL HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR WHEEL HUB ASSEMBLY) SENSOR CHECK INPUT IGNITION VOLTAGE STOP FUSE STOP LAMP SWITCH (LEFT SIDE OF DASH) VEH SPD SENS SIG BATTERY POSITIVE VOLT GROUND SERIAL DATA BUS- VIO WIRE WHT WIRE WHT/BLK WIRE

Get access

ABS IND. BATT POSITIVE VOLT BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR) BRAKE IND BRN WIRE COMPUTER DATA LINES SYSTEM DAYTIME RUNNING LIGHTS (DRL) MODULE (LEFT SIDE DK BLU WIRE DK GRN WIRE GROUND GRY WIRE HI SPD GMLAN I/P JUNCTION BLOCK (RIGHT SIDE OF DASH) IGNITION VOLT INSTRUMENT PANEL CLUSTER (IPC) LOGIC LT GRN WIRE OF DASH) PARKING BRAKE SWITCH (UNDER CENTER CONSOLE) RED WIRE SER DATA BUS - STEERING ANGLE SENSOR (TOP OF STEERING COLUMN) VEHICLE STABILITY CONTROL MODULE (LEFT SIDE OF DASH) VIO WIRE VSC OFF IND WHT WIRE WHT/BLK WIRE YAW RATE, LATERAL ACCELEROMETER SENSOR (UNDER DRIVER'S SEAT) YEL WIRE
