Compressor circuit for Pontiac Vibe II (2008-2010)

Compressor circuit

Get access

1 4 5 VOLT REF LOW REF A/C COMPRESSOR CLUTCH (LEFT FRONT OF ENGINE) A/C COMPRESSOR CLUTCH CTRL A/C REFRIGERANT PRESS SENS SIG A/C REFRIGERANT PRESSURE SENSOR BATT POSITIVE VOL BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE EVAPORATOR TEMP SENS SIG EVAPORATOR TEMPERATURE SENSOR (BOTTOM OF HVAC) FUSE GROUND HI SP GM LAN SERIAL DATA BUS- HOT AT ALL TIMES HVAC CONTROL MODULE (CENTER OF DASH) I/P FUSE BLOCK (LEFT END OF DASH) LOW REF LT BLU WIRE LT GRN WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VIO WIRE WHT WIRE WHT/BLK WIRE
