Pontiac Vibe II (2008-2010) theft deterrent key transponder Wiring diagrams
This page contains all the electrical diagrams for the component. theft deterrent key transponder, in which he is found in the car Pontiac Vibe II (2008-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram theft deterrent key transponder (1 of 2)
ACCESSORY POWER INVERTER MODULE
ACCESSORY POWER OUTLET
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
COURTESY/ READING LAMPS
DATA LINK CONNECTOR (DLC)
DRIVER DOOR LOCK SWITCH
DRIVER DOOR/ DRIVER LOCK DOOR WINDOW LOCK SWITCH ACTUATOR
FLASHER RELAY
I/P FUSE BLOCK (LEFT END OF DASH)
I/P JUNCTION BLOCK (RIGHT SIDE OF DASH)
IG 1 HTR RELAY RELAY
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT PANEL CLUSTER (IPC)
NOISE FILTER
OUTSIDE
PWR OUTLET RELAY
PWR PCB RELAY
REAR FRONT WINDOW WINDSHIELD WIPER/ WIPER/ WASHER WASHER SWITCH SWITCH
SECURITY INDICATOR LAMP
STEERING ANGLE SENSOR
SUNROOF MOTOR
SUNROOF SWITCH
THEFT DETERRENT KEY TRANSPONDER
THEFT DETERRENT MODULE (TDM)
THEFT DETERRENT SHOCK SENSOR
TIRE PRESSURE INDICATOR RESET SWITCH
TIRE PRESSURE MODULE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
VEHICLE STABILITY CONTROL MODULE
W/ POWER WINDOWS
W/O POWER WINDOWS
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> THEFT DETERRENT KEY TRANSPONDER
Wiring diagram theft deterrent key transponder (2 of 2)
1.8L
5 PNK/ WIRE
8 PNK WIRE
ALT-S FUSE ALT FUSE
AMP FUSE
AUDIO AMPLIFIER
AUXILIARY VEHICLE COMMUNICATION INTERFACE MODULE
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
COMPT)
COURTESY/ READING LAMPS
DCC RAD 1 FUSE FUSE
DIGITAL RADIO RECEIVER
DIMMER RELAY
DK BLU WIRE
DK GRN WIRE
DOME FUSE
DOME/ READING LAMPS
ECU-B FUSE
FLASHER RELAY
FROM RAD 1 FUSE (DIAGRAM 1 OF 5)
FUSE
FUSIBLE LINK
GENERATOR
H-LP RELAY
HAZ TURN FUSE H-LP MAIN FUSE
HVAC CONTROL MODULE
I/P FUSE BLOCK (LEFT END OF DASH)
I/P JUNCTION BLOCK (RIGHT SIDE OF DASH)
INSTRUMENT DAYTIME PANEL RUNNING CLUSTER LIGHTS (IPC) (DRL) MODULE
LT BLU WIRE
MAYDAY FUSE
PNK 1 6 W/O ROOF W/ ROOF WIRE
PNK 1 WIRE
PNK 14 WIRE
PNK 15 WIRE
PNK 5 WIRE
PNK WIRE
RADIO
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
STARTER
STEERING ANGLE SENSOR
THEFT DETERRENT KEY TRANSPONDER
THEFT THEFT DETERRENT DETERRENT MODULE SHOCK (TDM) SENSOR
TO ACC CUT RELAY (DIAGRAM 3 OF 5)
TO ECU-B FUSE (DIAGRAM 1 OF 5)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) TO P/I FUSE (DIAGRAM 2 OF 5)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> THEFT DETERRENT KEY TRANSPONDER
