Pontiac Vibe II (2008-2010) stp lp sw sig ign lk cyl sol ctrl ign sw sig st Wiring diagram
This page shows the only wiring diagram for the component.stp lp sw sig ign lk cyl sol ctrl ign sw sig st, which is found in the car Pontiac Vibe II (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stp lp sw sig ign lk cyl sol ctrl ign sw sig st (1 of 1)
1 2 3 4 5 6 7 8 GND
4 SPEED 5 SPEED A/T A/T
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID (UNDER CENTER CONSOLE)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK DK
DK GRN WIRE
ECU-IG 1 FUSE 6
ECU-IG 2 FUSE 7
FUSE 15
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT END OF DASH)
IGN VOL
IGNITION LOCK CYLINDER CONTROL SOLENOID (AT IGNITION SWITCH)
IGNITION SWITCH
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH,
PARK/ NEUTRAL POSITION (PNP) SWITCH (ON TRANS- MISSION)
RED WIRE
RELAY ENERGIZED
STOP FUSE 9
STOP LAMP SWITCH (LEFT SIDE OF DASH)
STP LP SW SIG IGN LK CYL SOL CTRL IGN SW SIG ST
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> STP LP SW SIG IGN LK CYL SOL CTRL IGN SW SIG ST
