Pontiac Vibe II (2008-2010) shift lever position indicator Wiring diagram
This page shows the only wiring diagram for the component.shift lever position indicator, which is found in the car Pontiac Vibe II (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift lever position indicator (1 of 1)
12 13 TAIL RLY CNTRL PRK LMPS GND
ACCESSORY AC/DC POWER CONTROL MODULE
AIR TEMPERATURE ACTUATOR
ALT FUSE
AUTOMATIC TRANSMISSION
BLK WIRE
BLOWER MOTOR SWITCH
BRN WIRE
CIGAR LIGHTER
DAYTIME RUNNING LIGHTS (DRL) MODULE (LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
HAZARD WARNING SWITCH
HEAD
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT END OF DASH)
I/P JUNCTION BLOCK (RIGHT SIDE OF DASH)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (UNDER STEERING WHEEL)
INSTRUMENT PANEL CLUSTER (IPC)
LAMP
LEFT STEERING WHEEL CONTROL SWITCH
LOGIC
METER FUSE 31
MODE ACTUATOR
PANEL FUSE 17
PARK OFF
PCB RELAY ENERGIZED
PNK WIRE
RADIO
RED WIRE
SHIFT LEVER POSITION INDICATOR
T-LP PCB RELAY
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK ECU-B FUSE (LEFT SIDE OF ENGINE COMPT)
VEHICLE STABILITY CONTROL MODULE (LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument illumination circuit -> SHIFT LEVER POSITION INDICATOR
