Pontiac Vibe II (2008-2010) rr rr wpr wpr com volt Wiring diagram
This page shows the only wiring diagram for the component.rr rr wpr wpr com volt, which is found in the car Pontiac Vibe II (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr rr wpr wpr com volt (1 of 1)
BLK WIRE
BRN WIRE
DK BLU WIRE
HOT W/ IG 1 RELAY ENERGIZED
I/P FUSE BLOCK (LEFT END OF DASH)
IGN VOLT
INT ON
LT GRN WIRE
OFF WASH
PNK WIRE
REAR WINDOW WASHER FLUID PUMP (IN WASHER FLUID RESERVOIR)
REAR WINDOW WIPER MOTOR (REAR LIFTGATE GLASS) GND
RR RR WPR WPR COM VOLT
RR WIPER FUSE 4
RR WPR SW SIG
VIO WIRE
WHT WIRE
Go to component -> Rear washer/wiper circuit -> RR RR WPR WPR COM VOLT
