Pontiac Vibe II (2008-2010) rf dr lk actuator sig Wiring diagrams
This page contains all the electrical diagrams for the component. rf dr lk actuator sig, in which he is found in the car Pontiac Vibe II (2008-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rf dr lk actuator sig (1 of 2)
4 10 PNK WIRE
5 2 3 1 PNK BATT(+) VOLT SERIAL DATA ENABLE SIG GROUND WIRE
AJAR SW RR DOOR
AUXILIARY VEHICLE COMMUNICATION INTERFACE MODULE
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DOOR FUSE 11 25 A
DRIVER DOOR JAMB SWITCH (LEFT "B" PILLAR)
DRIVER DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR) 1 2
DRIVER DOOR LOCK SWITCH
DRIVER DOOR LOCK/ WINDOW SWITCH
DRV DR KEY SW UNLK SIG
DRV DR LK POSITION SW IN
ENABLE SIG
HOT AT ALL TIMES
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) DOME FUSE
JAMB SW LR DOOR
KEY CYLINDER SWITCH
LEFT REAR DOOR JAMB SWITCH (LEFT "C" PILLAR)
LOCK DETECTION SWITCH
LOCK SW SIG
LT BLU WIRE
PASSENGER DOOR AJAR SW
PASSENGER DOOR JAMB SWITCH (RIGHT "B" PILLAR)
PASSENGER DOOR KEY SW
PASSENGER DOOR LOCK ACTUATOR (REAR OF RIGHT FRONT DOOR)
PASSENGER DOOR LOCK SWITCH
PNK WIRE
POSITION SW IN PASS DR LK
RED WIRE
RED/DK GRN WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (RIGHT "C" PILLAR)
RF DR LK ACTUATOR SIG
RIGHT REAR DOOR JAMB SWITCH (RIGHT "C" PILLAR)
SERIAL DATA
UN LOCK SW SIG
UNLK CTRL DRV DR LK MTR
VIO WIRE
W/ POWER WINDOWS
W/O POWER WINDOWS
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-theft circuit (1 of 2) -> RF DR LK ACTUATOR SIG
