Pontiac Vibe II (2008-2010) pnk htr sub 1 rly ctrl htr sub 3 rly ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. pnk htr sub 1 rly ctrl htr sub 3 rly ctrl, in which he is found in the car Pontiac Vibe II (2008-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk htr sub 1 rly ctrl htr sub 3 rly ctrl (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 BATT POSITIVE VOL
1 2 PNK WIRE
A/C COMPRESSOR CLUTCH (LEFT FRONT OF ENGINE)
A/C REQUEST SIG DIMMING SIG
A/C SWITCH
BLK WIRE
BLOWER MOTOR (RIGHT SIDE OF HVAC)
BLOWER MOTOR RESISTOR (AT BLOWER MOTOR)
BLOWER MOTOR SWITCH
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/WHT WIRE
DK GRN WIRE
ECU- IG 1 FUSE
ECU-IG 2 FUSE 7
EVAPORATOR TEMPERATURE SENSOR
FUSE
GRY WIRE
HEADLAMP RLY CTRL GENERATOR TURN ON SIG
HEADLIGHTS SYSTEM STARTING/ CHARGING SYSTEM
HEATED MIRROR SWITCH
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) HTR FUSE
HOT W/ IG 1 RELAY ENERGIZED
HTR RELAY
HTR REQUEST SIG
HTR-IG 2 FUSE 2
HVAC CONTROL MODULE (CENTER OF DASH)
HVAC MODE SWITCH
HVAC TEMPERATURE SWITCH
I/P FUSE BLOCK (LEFT END OF DASH)
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH,
LT BLU WIRE
LT GRN WIRE
PNK HTR SUB 1 RLY CTRL HTR SUB 3 RLY CTRL WIRE
PNK WIRE
RECIRCULATING SWITCH
RECIRCULATION ACTUATOR
RED WIRE
TOP OF ENGINE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD DEFROST SWITCH
YEL WIRE
Go to component -> 1.8l vin 8, manual a/c circuit (1 of 2) -> PNK HTR SUB 1 RLY CTRL HTR SUB 3 RLY CTRL WIRE
Wiring diagram pnk htr sub 1 rly ctrl htr sub 3 rly ctrl (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 BATT POSITIVE VOL
1 2 PNK WIRE
A/C COMPRESSOR CLUTCH (LEFT FRONT OF ENGINE)
A/C REQUEST SIG DIMMING SIG
A/C SWITCH
BLK WIRE
BLOWER MOTOR (RIGHT SIDE OF HVAC)
BLOWER MOTOR RESISTOR (AT BLOWER MOTOR)
BLOWER MOTOR SWITCH
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/WHT WIRE
DK GRN WIRE
ECU- IG 1 FUSE
ECU-IG 2 FUSE 7
EVAPORATOR TEMPERATURE SENSOR
FUSE
GRY WIRE
HEADLAMP RLY CTRL GENERATOR TURN ON SIG
HEADLIGHTS SYSTEM STARTING/ CHARGING SYSTEM
HEATED MIRROR SWITCH
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) HTR FUSE
HOT W/ IG 1 RELAY ENERGIZED
HTR RELAY
HTR REQUEST SIG
HTR-IG 2 FUSE 2
HVAC CONTROL MODULE (CENTER OF DASH)
HVAC MODE SWITCH
HVAC TEMPERATURE SWITCH
I/P FUSE BLOCK (LEFT END OF DASH)
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH,
LT BLU WIRE
LT GRN WIRE
PNK HTR SUB 1 RLY CTRL HTR SUB 3 RLY CTRL WIRE
PNK WIRE
RECIRCULATING SWITCH
RECIRCULATION ACTUATOR
RED WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD DEFROST SWITCH
YEL WIRE
Go to component -> 2.4l vin 0, manual a/c circuit (1 of 2) -> PNK HTR SUB 1 RLY CTRL HTR SUB 3 RLY CTRL WIRE
