Pontiac Vibe II (2008-2010) intermediate lo spd spd wip wip sig sig Wiring diagram
This page shows the only wiring diagram for the component.intermediate lo spd spd wip wip sig sig, which is found in the car Pontiac Vibe II (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intermediate lo spd spd wip wip sig sig (1 of 1)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
FRONT WINDSHIELD WASHER FLUID PUMP (IN WASHER FLUID RESERVOIR)
FRONT WINDSHIELD WIPER/ WASHER SWITCH
HIGH LOW OFF INT
HOT W/ IG 1 RELAY ENERGIZED
I/P FUSE BLOCK (LEFT END
IGN PUMP VOLT CTRL
INTERMEDIATE LO SPD SPD WIP WIP SIG SIG
LOGIC
LOW OFF INT
MIST
OF DASH)
RED WIRE
WASH
WASH SWITCH
WASHER FUSE 5
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WIPER FUSE 3
