Pontiac Vibe II (2008-2010) inflatable restraint front passenger presence system Wiring diagram
This page shows the only wiring diagram for the component.inflatable restraint front passenger presence system, which is found in the car Pontiac Vibe II (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inflatable restraint front passenger presence system (1 of 1)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER SEAT BELT PRETENSIONER (BASE OF LEFT "B" PILLAR)
GRY WIRE
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM
LEFT INFLATABLE RESTRAINT FRONT END SENSOR (LEFT FRONT OF ENGINE COMPT)
LOW REF RH SIG GND
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSENGER SEAT BELT BUCKLE (FRONT PASSENGER'S SEAT BELT BUCKLE ASSEMBLY)
PASSENGER SEAT BELT PRETENSIONER (BASE OF RIGHT "B" PILLAR)
PASSENGER SEAT BELT SWITCH
PNK WIRE
RED WIRE
RIGHT INFLATABLE RESTRAINT FRONT END SENSOR (RIGHT FRONT OF ENGINE COMPT)
SECURITY INDICATOR LAMP
SHORTING BAR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM
