Pontiac Vibe II (2008-2010) htr sub 1 relay Wiring diagrams
This page contains all the electrical diagrams for the component. htr sub 1 relay, in which he is found in the car Pontiac Vibe II (2008-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
htr sub 1 relay wiring diagram (1 of 2)
1 2 3 B+ COOLING FAN RLY CTRL GND
97 96 ECT SENS SIG LOW REF
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN RLY CTRL HI SP GMLAN SERIAL DATA BUS-
DK BLU WIRE
DK BLU/BLK WIRE
ENGINE COOLANT
FAN 1 RELAY
FAN CONTROL MODULE (BEHIND RADIATOR)
HI SP GMLAN SERIAL DATA BUS+
HOT AT ALL TIMES
HTR SUB 1 FUSE
HTR SUB 1 RELAY
HTR SUB 3 FUSE
HTR SUB 3 RELAY
HVAC HEATER ELEMENT
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
RDI FAN FUSE
RED/DK GRN WIRE
RIGHT END OF DASH)
TEMPERATURE (ECT) SENSOR (REAR OF CYLINDER HEAD)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD RELAY BLOCK (RIGHT REAR OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/DK BLU WIRE
YEL WIRE
Go to component -> 1.8l vin 8, manual a/c circuit (2 of 2) -> HTR SUB 1 RELAY
htr sub 1 relay wiring diagram (2 of 2)
97 96 ECT SENS SIG LOW REF
BLK WIRE
BLU WIRE
BRN WIRE
CDS FAN FUSE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/BLK WIRE
ENGINE COOLANT
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
HI SP GMLAN SERIAL DATA BUS+
HOT AT ALL TIMES
HTR SUB 1 FUSE
HTR SUB 1 RELAY
HTR SUB 3 FUSE
HTR SUB 3 RELAY
HVAC HEATER ELEMENT
LEFT ENGINE COOLING FAN (BEHIND RADIATOR)
LO SP COOLING FAN RLY CTRL HI SP COOLING FAN RLY CTRL
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
RDI FAN FUSE
RED WIRE
RIGHT END OF DASH)
RIGHT ENGINE COOLING FAN (BEHIND RADIATOR)
TEMPERATURE (ECT) SENSOR (REAR OF CYLINDER HEAD)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD RELAY BLOCK (RIGHT REAR OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
WHT/DK BLU WIRE
YEL WIRE
Go to component -> 2.4l vin 0, manual a/c circuit (2 of 2) -> HTR SUB 1 RELAY
