Pontiac Vibe II (2008-2010) def pcb relay Wiring diagrams

BLK WIRE BLOWER MOTOR SWITCH BRN WIRE DEF FUSE DEF PCB RELAY DEFOGGER IND DEFOGGER SWITCH DK BLU WIRE ECU-IG 2 FUSE 7 HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED HTR-IG FUSE 2 I/P FUSE BLOCK (LEFT END OF DASH) LEFT "C" PILLAR) POWER DISTRIBUTION SYSTEM RADIO REAR WINDOW DEFOGGER CAPACITOR (TOP OF LEFT "C" PILLAR) REAR WINDOW DEFOGGER GRID RED WIRE WHT WIRE WHT/BLK WIRE

1 2 3 4 5 6 7 8 B+ A/T M/T ACCESSORY AC/DC POWER CONTROL MODULE ACCESSORY POWER INVERTER MODULE ACCESSORY POWER OUTLET AUDIO AMPLIFIER AUXILIARY VEHICLE COMMUNICATION INTERFACE MODULE BLK WIRE BODY CONTROL MODULE C/OPN PCB RELAY CIG FUSE 23 CIGAR LIGHTER DEF PCB RELAY DK BLU WIRE DK GRN WIRE ECU-IG 2 FUSE 7 FLASHER RELAY FROM FROM ACC RELAY (DIAGRAM 3 OF 5) FROM ECU-IG 1 FUSE (DIAGRAM 4 OF 5) FROM EFI 1 FUSE (DIAGRAM 2 OF 5) FROM HTR FUSE (DIAGRAM 2 OF 5) FROM I/P FUSE BLOCK (DIAGRAM 3 OF 5) FROM IGN FUSE (DIAGRAM 5 OF 5) FROM UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 5) FUSE 24 GRY WIRE HTR PCB RELAY I/P FUSE BLOCK (LEFT END OF DASH) I/P JUNCTION BLOCK (RIGHT SIDE OF DASH) I/P RELAY BLOCK (CENTER OF DASH) IGN FUSE 30 INSTRUMENT PANEL CLUSTER (IPC) LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH, METER FUSE 31 OUTSIDE REARVIEW MIRROR SWITCH PARK/ BACKUP GENERATOR NEUTRAL LAMP POSITION SWITCH (PNP) SWITCH POWERTRAIN CONTROL MODULE (PCM) PWR OUTLET RELAY RADIO RED WIRE SECURITY INDICATOR LAMP SERIAL DATA GATEWAY (SDG) MODULE STOP LAMP SWITCH TO C/OPN PCB RELAY (DIAGRAM 5 OF 5) VIO WIRE W/ CHASSIS WHT WIRE WHT/BLK WIRE YEL WIRE
