Pontiac Vibe II (2008-2010) accessory ac/dc power control module Wiring diagrams
This page contains all the electrical diagrams for the component. accessory ac/dc power control module, in which he is found in the car Pontiac Vibe II (2008-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram accessory ac/dc power control module (1 of 2)
12 13 TAIL RLY CNTRL PRK LMPS GND
ACCESSORY AC/DC POWER CONTROL MODULE
AIR TEMPERATURE ACTUATOR
ALT FUSE
AUTOMATIC TRANSMISSION
BLK WIRE
BLOWER MOTOR SWITCH
BRN WIRE
CIGAR LIGHTER
DAYTIME RUNNING LIGHTS (DRL) MODULE (LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
HAZARD WARNING SWITCH
HEAD
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT END OF DASH)
I/P JUNCTION BLOCK (RIGHT SIDE OF DASH)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (UNDER STEERING WHEEL)
INSTRUMENT PANEL CLUSTER (IPC)
LAMP
LEFT STEERING WHEEL CONTROL SWITCH
LOGIC
METER FUSE 31
MODE ACTUATOR
PANEL FUSE 17
PARK OFF
PCB RELAY ENERGIZED
PNK WIRE
RADIO
RED WIRE
SHIFT LEVER POSITION INDICATOR
T-LP PCB RELAY
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK ECU-B FUSE (LEFT SIDE OF ENGINE COMPT)
VEHICLE STABILITY CONTROL MODULE (LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument illumination circuit -> ACCESSORY AC/DC POWER CONTROL MODULE
Wiring diagram accessory ac/dc power control module (2 of 2)
1 2 3 4 5 6 7 8 B+
A/T M/T
ACCESSORY AC/DC POWER CONTROL MODULE
ACCESSORY POWER INVERTER MODULE
ACCESSORY POWER OUTLET
AUDIO AMPLIFIER
AUXILIARY VEHICLE COMMUNICATION INTERFACE MODULE
BLK WIRE
BODY CONTROL MODULE
C/OPN PCB RELAY
CIG FUSE 23
CIGAR LIGHTER
DEF PCB RELAY
DK BLU WIRE
DK GRN WIRE
ECU-IG 2 FUSE 7
FLASHER RELAY
FROM
FROM ACC RELAY (DIAGRAM 3 OF 5)
FROM ECU-IG 1 FUSE (DIAGRAM 4 OF 5)
FROM EFI 1 FUSE (DIAGRAM 2 OF 5)
FROM HTR FUSE (DIAGRAM 2 OF 5)
FROM I/P FUSE BLOCK (DIAGRAM 3 OF 5)
FROM IGN FUSE (DIAGRAM 5 OF 5)
FROM UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 5)
FUSE 24
GRY WIRE
HTR PCB RELAY
I/P FUSE BLOCK (LEFT END OF DASH)
I/P JUNCTION BLOCK (RIGHT SIDE OF DASH)
I/P RELAY BLOCK (CENTER OF DASH)
IGN FUSE 30
INSTRUMENT PANEL CLUSTER (IPC)
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH,
METER FUSE 31
OUTSIDE REARVIEW MIRROR SWITCH
PARK/ BACKUP GENERATOR NEUTRAL LAMP POSITION SWITCH (PNP) SWITCH
POWERTRAIN CONTROL MODULE (PCM)
PWR OUTLET RELAY
RADIO
RED WIRE
SECURITY INDICATOR LAMP
SERIAL DATA GATEWAY (SDG) MODULE
STOP LAMP SWITCH
TO C/OPN PCB RELAY (DIAGRAM 5 OF 5)
VIO WIRE
W/ CHASSIS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> ACCESSORY AC/DC POWER CONTROL MODULE
