Pontiac Vibe II (2008-2010) 1 2 3 4 5 6 mtr resolver sin mtr resolver cos Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 mtr resolver sin mtr resolver cos, which is found in the car Pontiac Vibe II (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 mtr resolver sin mtr resolver cos (1 of 1)
+5 V
1 2 3 4 5 6 7 8 9 10 11 12 DATA BUS (+)
1 2 3 4 5 6 MTR RESOLVER SIN MTR RESOLVER COS
1 2 B+ GND
27 28 COMPUTER DATA LINES SYSTEM
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
ELECTRIC POWER STEERING (EPS) MODULE (LEFT SIDE OF DASH)
ELECTRIC POWER STEERING (ESP) MOTOR
GRN WIRE
HOT AT ALL TIMES ESP FUSE
HOT W/ IG 1 RELAY ENERGIZED ECU-IG 1 FUSE 6
HOT W/ IG 2 PCB RELAY ENERGIZED METER FUSE 31
I/P FUSE BLOCK (LEFT END OF DASH)
IGN VOLT DATA BUS (-)
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
LOW REFERENCE
LT BLU WIRE
POWER STEERING MTR PHASE U
POWER STEERING MTR PHASE V
POWER STEERING MTR PHASE W
RED WIRE
RESOLVER MOTOR
STEERING IND
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
Go to component -> Electronic power steering circuit -> 1 2 3 4 5 6 MTR RESOLVER SIN MTR RESOLVER COS
