Rear washer/wiper circuit for Pontiac Vibe I facelift (2002-2008)
Rear washer/wiper circuit
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
DEFOGGER SYSTEM
FRONT WASHER MOTOR (AT RIGHT FRONT SIDE OF ENGINE COMPT)
GAUGE FUSE
GLASS HATCH COURTESY SWITCH
HOT IN RUN OR START
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LEFT INSTRUMENT
ON OFF INT
PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
PARK
PNK WIRE
REAR HATCH GLASS CONNECTOR
REAR WASHER MOTOR
REAR WIPER
REAR WIPER DIODE 1 (BEHIND LEFT END OF DASH)
REAR WIPER DIODE 2
REAR WIPER LOGIC
REAR WIPER RELAY 1 (BEHIND LEFT END OF DASH)
REAR WIPER RELAY 2
RED/BLK WIRE
RED/WHT WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RR WIP FUSE
RUN WIRE
WASH
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WIPE/WASH
WIPER/ WASHER SWITCH
