Starting circuit, m/t for Pontiac Vibe I facelift (2002-2008)
Starting circuit, m/t
1.8L (VIN 8) FWD
AWD, W/ ANTI-THEFT
AWD, W/O ANTI-THEFT
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
FUSE
FUSIBLE LINK (14 GA-
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LOCK
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH)
RED WIRE
ST RELAY
STARTER
STARTER CUT RELAY (BEHIND RIGHT SIDE OF DASH)
THEFT DETERRENT CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
