Back-up lamps circuit for Pontiac Vibe I facelift (2002-2008)
Back-up lamps circuit
A/T
BACK-UP LAMP SWITCH (ON TOP OF TRANSAXLE)
GAUGE FUSE
HOT IN RUN OR START
INSTRUMENT PANEL CLUSTER (1.8L VIN L)
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LAMP
LEFT BACK-UP LAMP
M/T
NAVIGATION RADIO (IF EQUIPPED)
PARK/NEUTRAL POSITION SWITCH (ON TRANSMISSION)
RED/BLK WIRE
RED/WHT WIRE
RIGHT BACK-UP
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
WHT/BLK WIRE
