Pontiac Vibe I facelift (2002-2008) wiper/ washer switch front wiper motor Wiring diagram
This page shows the only wiring diagram for the component.wiper/ washer switch front wiper motor, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper/ washer switch front wiper motor (1 of 1)
ABS 1 FUSE
ABS 2 FUSE
ABS CUT-OFF RELAY
ABS UNDERHOOD FUSE BLOCK (ATTACHED TO LF STRUT TOWER, NEAR UNDERHOOD FUSE BLOCK)
AC/FRESH/ RECIR- CULATION SWITCH CRUISE CONTROL RELEASE SWITCH
BACKUP LAMP SWITCH (M/T)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE PRESSURE MODULATOR VALVE (BPMV)
BRN WIRE
DAYTIME RUNNING LAMPS (DRL) CONTROL MODULE
DEF FUSE
DEF RELAY
DEF- I/UP FUSE
FAN 1 RELAY
FAN 2 RELAY
FOG FUSE
FOG RELAY
FROM ALT FUSE (DIAGRAM 1 OF 4)
FRONT WASHER MOTOR
GAUGE FUSE ECU-IG FUSE
GLASS BREAKAGE SENSOR (W/ THEFT DETERENT) THEFT DETERRENT MODULE
GRN WIRE
HEATER FUSE
HEATER RELAY
INSTRUMENT PANEL FUSE BLOCK
MULTI- FUNCTION ALARM MODULE IG 1 RELAY
NOISE FILTER
P/W RELAY
PASSENGER SEAT BELT/ AIRBAG ON/OFF INDICATOR
POWERTRAIN CONTROL MODULE (PCM)
RDI FAN FUSE
REAR DEFOGGER NOISE FILTER
REAR WASHER MOTOR
REAR WIPER DIODE (IN ENGINE ACCESSORY HARN, NEAR PCM)
REAR WIPER RELAY 1
RED WIRE
RIGHT REAR DEFOGGER INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RR WIP FUSE WASH FUSE
SENSOR (W/ VSC) SENSOR (W/ VSC)
SHIFTLOCK CONTROL MODULE
TO 115 VOLT POWER OUTLET SWITCH (DIAGRAM 3 OF 4)
TO ECU B FUSE (DIAGRAM 3 OF 4)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, MOUNTED TO INNER FENDER)
W/ VSC
W/ VSC 16 2 W/O VSC BRAKE PRESSURE MODULATOR VALVE (BPMV)
W/O VSC
WHT WIRE
WIPER FUSE
WIPER/ WASHER SWITCH FRONT WIPER MOTOR
Go to component -> Power distribution circuit (2 of 4) -> WIPER/ WASHER SWITCH FRONT WIPER MOTOR
