Pontiac Vibe I facelift (2002-2008) vehicle stability ctrl ind Wiring diagram
This page shows the only wiring diagram for the component.vehicle stability ctrl ind, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle stability ctrl ind (1 of 1)
1 2 3 9 10 IGN VOL GND BATT CAN LOW CAN HIGH
ABS 1 FUSE ABS 2 FUSE
ABS CUT-OFF RELAY
ABS MOTOR RELAY
ABS UNDERHOOD FUSE BLOCK (ATTACHED TO LF STRUT TOWER, NEAR UNDERHOOD FUSE BLOCK)
ABS WARNING IND
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE IND
CONNECTOR (DLC))
FAN 2 RELAY
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
PNK WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
SLIP IND
STEERING ANGLE SENSOR (TOP OF STEERING COLUMN, BELOW STEERING WHEEL)
VEHICLE STABILITY CONTROL AUDIBLE WARNING
VEHICLE STABILITY CTRL IND
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YAW, LATERAL ACCELERATION SENSOR (UNDER DRIVER SEAT)
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit, with vsc (2 of 2) -> VEHICLE STABILITY CTRL IND
