Pontiac Vibe I facelift (2002-2008) theft deterrent control module Wiring diagram
This page shows the only wiring diagram for the component.theft deterrent control module, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram theft deterrent control module (1 of 1)
21 33 40 34 6 41 W/ VSC W/O VSC
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BUZZER
DOME FUSE (LEFT SIDE OF ENGINE COMPT)
DOOR FUSE
DOOR OPEN IND
DRIVER SEAT BELT BUCKLE SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
ECT SIG
GAUGE FUSE
GRN WIRE
HEADLAMPS ON IND
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION KEY ALARM SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LEFT FRONT COURTESY SWITCH
LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT
LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MOUNTED TO INNER FENDER)
MULTI-FUNCTION ALARM MODULE
PASSENGER SEAT BELT WARNING LAMP
PPL
RED WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
SEAT BELT IND
SIDE OF DASH)
THEFT DETERRENT CONTROL MODULE
TIRE PRESSURE IND
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Warning systems circuit -> THEFT DETERRENT CONTROL MODULE
