Pontiac Vibe I facelift (2002-2008) tcc solenoid shift solenoid 2 shift solenoid 1 Wiring diagrams
This page contains all the electrical diagrams for the component. tcc solenoid shift solenoid 2 shift solenoid 1, in which he is found in the car Pontiac Vibe I facelift (2002-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tcc solenoid shift solenoid 2 shift solenoid 1 (1 of 2)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE PRESSURE MODULATOR VALVE (AT RIGHT FRONT SIDE OF ENGINE COMPT)
BRAKE SOLENOID
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (BEHIND LEFT SIDE OF DASH, TOP OF STEERING COLUMN BRACKET)
ECT IN
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION
INSIDE VEHICLE)
INSTRUMENT PANEL CLUSTER O/D OFF IND MALFUNCTION INDICATOR LAMP
INTAKE AIR TEMP
JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
KNOCK SENSOR (FRONT CENTER OF ENGINE COMPT, BELOW INTAKE MANIFOLD)
LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LINE PRESSURE CONTROL SOLENOID
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MASS AIR FLOW SENSOR (TOP OF AIR CLEANER ASSEMBLY)
NAVIGATION RADIO (IF EQUIPPED)
NCA WIRE
PNK WIRE
PNK/BLK WIRE
PPL/ WHT WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
STOP FUSE
STOPLAMP SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT BRACKET)
TACH IN
TCC SOLENOID SHIFT SOLENOID 2 SHIFT SOLENOID 1
TRANSMISSION CONNECTOR
TRANSMISSION FLUID TEMPERATURE SENSOR
VS IN
W/ VSC
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8, awd (2 of 3) -> TCC SOLENOID SHIFT SOLENOID 2 SHIFT SOLENOID 1
Wiring diagram tcc solenoid shift solenoid 2 shift solenoid 1 (2 of 2)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE PRESSURE MODULATOR VALVE (AT RIGHT FRONT SIDE OF ENGINE COMPT)
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECT IN
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION
INSTRUMENT PANEL CLUSTER O/D OFF IND MALFUNCTION INDICATOR LAMP
INTAKE AIR TEMP
JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
KNOCK SENSOR (FRONT CENTER OF ENGINE COMPT, BELOW INTAKE MANIFOLD)
LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LINE PRESSURE CONTROL SOLENOID
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MASS AIR FLOW SENSOR (TOP OF AIR CLEANER ASSEMBLY)
NAVIGATION RADIO (IF EQUIPPED)
NCA WIRE
PNK WIRE
PNK/BLK WIRE
PPL/ WHT WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
STOP FUSE
STOPLAMP SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT BRACKET)
TACH IN
TCC SOLENOID SHIFT SOLENOID 2 SHIFT SOLENOID 1
TRANSMISSION CONNECTOR
VS IN
W/ VSC
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8, fwd (2 of 3) -> TCC SOLENOID SHIFT SOLENOID 2 SHIFT SOLENOID 1
