Pontiac Vibe I facelift (2002-2008) rf whl spd sig lo rf whl spd sig hi tire pressure sw Wiring diagram

ABS 1 FUSE ABS 2 FUSE ABS PUMP MOTOR ABS WARNING IND BATT SOLENOID GND TIRE PRESSURE AMBIENT TEMP SENS BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE IND BRK IND CTRL RR WHL SPD SIG HI RR WHL SPD SIG LO IGN POSITIVE VOL COLUMN SUPPORT BRACKET) COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DAYTIME RUNNING LAMPS (DRL) CONTROL MODULE (AT RIGHT SIDE OF DECELERATION SENSOR (AWD) (UNDER DRIVER'S SEAT) DRL MODULE ECU-IG FUSE FAN 1 RELAY GAUGE FUSE GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START IGNITION SWITCH INSTRUMENT PANEL CLUSTER LEFT FRONT SOLENOID VALVE LEFT FRONT WHEEL SPEED SENSOR (AT FRONT STEERING KNUCKLE ASSEMBLY) LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LEFT REAR SOLENOID VALVE LEFT REAR WHEEL SPEED SENSOR (AT REAR WHEEL HUB ASSEMBLY) LOCK LT GRN WIRE MOTOR GND BATT ORG/ WIRE PMP MTR HI PMP MTR LO PNK/BLK WIRE PNP SW PARK SIG PRK NEUTRAL SW DECELERATION SENS RED WIRE RED/WHT WIRE RF WHL SPD SIG LO RF WHL SPD SIG HI TIRE PRESSURE SW RIGHT FRONT SOLENOID VALVE RIGHT FRONT WHEEL SPEED SENSOR (AT FRONT STEERING KNUCKLE ASSEMBLY) RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH) RIGHT REAR SOLENOID VALVE RIGHT REAR WHEEL SPEED SENSOR (AT REAR WHEEL HUB ASSEMBLY) RUN WIRE SERIAL DATA BRAKE SW IN LR WHL SPD SIG HI LR WHL SPD SIG LO ABS IND CTRL VSS IN SIR SERIAL DATA LF WHL SPD SIG LO LF WHL SPD SIG HI SIR SERIAL DATA SERIAL DATA SOLENOID VALVE CONTROL SIGNALS STEERING COLUMN, ABOVE BRAKE PEDAL) STOP LAMP SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT BRACKET) TRACTION CTRL GND TRANSMISSIONS SYSTEM VIO/WHT WIRE WARNING SYSTEM WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
