Pontiac Vibe I facelift (2002-2008) raop sw in evap temp sens ac on sig air pressure Wiring diagram
This page shows the only wiring diagram for the component.raop sw in evap temp sens ac on sig air pressure, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram raop sw in evap temp sens ac on sig air pressure (1 of 1)
A/C RESISTOR (BEHIND RIGHT SIDE OF DASH)
AIR CONDITIONING SYSTEM
AUXILIARY INTAKE AIR CONTROL SOLENOID (AT FRONT OF AIR CLEANER ASSEMBLY)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE SIGNAL
BRN WIRE
CAMSHAFT POSITION (CMP) SENSOR (AT LEFT REAR OF ENGINE, ON CYLINDER HEAD)
CRUISE CONTROL SYSTEM
CRUISE IND
ECT OUT SERIAL DATA LINE CIRCUIT OPEN REL VSS IN
ECT SENS IN IAT IN TP SENS IN
ENG SPEED OUT EFI RLY CTRL HIGH AC CLUTCH RELAY
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 4 IGNITION COIL 3
LT GRN WIRE
NCA WIRE
NOISE FILTER (AT LEFT REAR OF ENGINE)
PLUG SPARK
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH)
PPL/WHT WIRE
RAOP SW IN EVAP TEMP SENS AC ON SIG AIR PRESSURE
RED WIRE
RED/BLU WIRE
SENSOR GROUND
SPARK PLUG
STARTING/ CHARGING SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l vin l (3 of 3) -> RAOP SW IN EVAP TEMP SENS AC ON SIG AIR PRESSURE
