Pontiac Vibe I facelift (2002-2008) p-point relay inv relay Wiring diagram
This page shows the only wiring diagram for the component.p-point relay inv relay, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram p-point relay inv relay (1 of 1)
A/C FRESH RECIRCULATION SWITCH
A/C/ FRESH/ RECIRCULATION SWITCH ILLUMINATION
BLK WIRE
BLOWER MOTOR SWITCH ILLUMINATION
DEFOGGER SWITCH ILLUMINATION
DRIVER SEAT BELT SWITCH
FRONT CIGAR LIGHTER ILLUMINATION
HAZARD SWITCH ILLUMINATION
HAZARD SWITCH OVERDRIVE SWITCH
OVERDRIVE SWITCH ILLUMINATION
P-POINT RELAY INV RELAY
PASSENGER SEAT BELT WARNING LAMP
POWER OUTLET SWITCH
POWER OUTLET SWITCH ILLUMINATION
RADIO ILLUMINATION
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
SECURITY INDICATOR
SHIFT LOCK CONTROL MODULE
TRACTION CONTROL OFF SWITCH
TRACTION CONTROL OFF SWITCH ILLUMINATION
W/ STABILITRAK
WHT WIRE
WHT/BLK WIRE
YAW, LATERAL ACCELERATION SENSOR STEERING ANGLE SENSOR
Go to component -> Ground distribution circuit (4 of 4) -> P-POINT RELAY INV RELAY
