Pontiac Vibe I facelift (2002-2008) line transmission fluid temperature sensor pressure control solenoid Wiring diagram

1.8L (VIN L) 1.8L-VIN 8 18 17 VS IN VS OUT 26 34 REF HIGH REF LOW ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/ WHT WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE COMPT) EFI RELAY LOCK EFI FUSE FUSE BLOCK UNDERHOOD (LEFT SIDE OF ENGINE COMPT, MOUNTED TO INNER FENDER) GAUGE FUSE (LEFT OF STEERING COLUMN, BEHIND STORAGE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES HOT AT ALL TIMES HOT IN RUN OR START IGN POS VOL EFI RLY CTRL BATT POS VOL IGN VOLT IGNITION SWITCH INPUT SHAFT SPEED SENSOR INSTRUMENT PANEL CLUSTER INSTRUMENT PANEL FUSE BLOCK INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT) JUNCTION BLOCK JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH) LINE TRANSMISSION FLUID TEMPERATURE SENSOR PRESSURE CONTROL SOLENOID LOCK LOGIC LT GRN WIRE LT GRN/BLK WIRE NAVIGATION RADIO (IF EQUIPPED) NCA WIRE O/D OFF IND PARK/NEUTRAL POSITION SWITCH (ON TRANSMISSION) PCM INSIDE VEHICLE) PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT INSTRUMENT PANEL SHIFT SOL #2 SHIFT SOL 1 TCC SOL BRAKE SOL SOLID STATE STOP FUSE STOP LAMP SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT BRACKET) TRANSMISSION CONNECTOR UNDERHOOD FUSE BOX) W/ ABS W/O ABS WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
