Pontiac Vibe I facelift (2002-2008) left front passenger presence sensor Wiring diagram

1 2 3 4 5 6 7 8 9 BATTERY 4 5 PNK WIRE BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ECU-B FUSE FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE GAUGE FUSE GRN WIRE GROUND GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START IGN VOLT INFLATABLE RESTRAINT LEFT FRONT DISCRI- MINATING SENSOR INFLATABLE RESTRAINT RIGHT FRONT DISCRI- MINATING SENSOR INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT) LEFT FRONT PASSENGER PRESENCE SENSOR LEFT FRONT SEAT BELT PRETENSIONER (AT LEFT "B" PILLAR) LEFT REAR PASSENGER PRESENCE SENSOR LT BLU WIRE ORG/ WIRE PASSENGER SEAT BELT SWITCH 1 2 PASSENGER SEAT BELT/ AIR BAG ON/OFF INDICATOR PNK WIRE PPL RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT PASSENGER PRESENCE SENSOR RIGHT FRONT SEAT BELT PRETENSIONER (AT RIGHT "B" PILLAR) RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH) RIGHT REAR PASSENGER PRESENCE SENSOR SHORTING BAR SIGNAL WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
