Pontiac Vibe I facelift (2002-2008) (in engine harness, near pcm Wiring diagrams
This page contains all the electrical diagrams for the component. (in engine harness, near pcm, in which he is found in the car Pontiac Vibe I facelift (2002-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
(in engine harness, near pcm wiring diagram (1 of 2)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
C/OPN RELAY
CIG FUSE
CLUTCH PEDAL POSITION (CPP) SWITCH
FROM AM 1 FUSE (DIAGRAM 3 OF 4)
FROM AM 2 FUSE (DIAGRAM 1 OF 4)
FRONT CIGAR LIGHTER
FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 4
FUEL SENDER ASSEMBLY
FUSE
GRY WIRE
IG 1 RELAY
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT OF
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LOCK
NOISE FILTER
ORG/ WIRE
PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
PARK/ NEUTRAL POSITION (PNP) SWITCH
POWER MIRROR SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RADIO
RED WIRE
RIGHT INSTRUMENT
RUN WIRE
STEERING COLUMN, BEHIND STORAGE COMPT)
TO P/POINT RELAY (DIAGRAM 3 OF 4)
VEHICLE INTERFACE UNIT (VIU)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> (IN ENGINE HARNESS, NEAR PCM
(in engine harness, near pcm wiring diagram (2 of 2)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE PRESSURE MODULATOR VALVE (AT RIGHT FRONT SIDE OF ENGINE COMPT)
BRAKE SOLENOID
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (BEHIND LEFT SIDE OF DASH, TOP OF STEERING COLUMN BRACKET)
ECT IN
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION
INSIDE VEHICLE)
INSTRUMENT PANEL CLUSTER O/D OFF IND MALFUNCTION INDICATOR LAMP
INTAKE AIR TEMP
JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
KNOCK SENSOR (FRONT CENTER OF ENGINE COMPT, BELOW INTAKE MANIFOLD)
LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LINE PRESSURE CONTROL SOLENOID
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MASS AIR FLOW SENSOR (TOP OF AIR CLEANER ASSEMBLY)
NAVIGATION RADIO (IF EQUIPPED)
NCA WIRE
PNK WIRE
PNK/BLK WIRE
PPL/ WHT WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT INSTRUMENT PANEL
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
STOP FUSE
STOPLAMP SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT BRACKET)
TACH IN
TCC SOLENOID SHIFT SOLENOID 2 SHIFT SOLENOID 1
TRANSMISSION CONNECTOR
TRANSMISSION FLUID TEMPERATURE SENSOR
VS IN
W/ VSC
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8, awd (2 of 3) -> (IN ENGINE HARNESS, NEAR PCM
