Pontiac Vibe I facelift (2002-2008) ignition ac request sig mil ctrl idle-up tail idle-up defog sir fuel cutoff Wiring diagram

AIR CONDITIONING SYSTEM AIR PUMP FUSE BATTERY AIR SOL CTRL AIR PUMP REL BLK RED/ WIRE BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE CIRCUIT OPENING RELAY COOLING FANS SYSTEM DEFOGGER SYSTEM DIAGNOSTIC FTP SIG EFI FUSE EFI RELAY EVAP PURGE SOL FAN 1 RLY CTRL FUEL SENDER FUEL PUMP ASSEMBLY (UNDER REAR SEAT CUSHION, BENEATH ACCESS FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPARTMENT) GRN WIRE GRN/RED WIRE GROUND VACUUM PUMP FAN 2 RLY CTRL GRY WIRE HEATED OXYGEN SENSOR 1 (AT REAR OF ENGINE COMPARTMENT, IN EXHAUST MANIFOLD) HI ROCKER ARM LOW ROCKER ARM HOT AT ALL TIMES IGN GROUND IGNITION AC REQUEST SIG MIL CTRL IDLE-UP TAIL IDLE-UP DEFOG SIR FUEL CUTOFF IGNITION SWITCH INSTRUMENT PANEL LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LOCK LT GRN WIRE PANEL ON TOP OF FUEL TANK) PNK WIRE PNK/BLK WIRE POWER STEERING PRESSURE SWITCH (AT TOP OF POWER STEERING PUMP) POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH) PSP SIGNAL RED WIRE RED/WHT WIRE RED/YEL WIRE ROCKER ARM OIL CONTROL VALVE SOLENOID (ON LEFT SIDE OF CYLINDER HEAD) SPLICE SUPPLEMENTAL RESTRAINTS SYSTEM UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT, MOUNTED TO INNER FENDER) WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE YEL WIRE
