Pontiac Vibe I facelift (2002-2008) evap vent sol sensor gnd low maf sig high maf sig tp sen 2 sig Wiring diagram
This page shows the only wiring diagram for the component.evap vent sol sensor gnd low maf sig high maf sig tp sen 2 sig, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram evap vent sol sensor gnd low maf sig high maf sig tp sen 2 sig (1 of 1)
A/C RESISTOR (BEHIND RIGHT SIDE OF DASH)
AC REQUEST OD SWITCH IN
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE SIG
BRN WIRE
COOLING FANS SYSTEM
CRUISE CONTROL SYSTEM
CRUISE CTRL SW
ECT SENS IN IAT SENS IN TP SENS 1 IN
ENGINE COOLANT TEMPERATURE SENSOR (AT LEFT SIDE OF CYLINDER HEAD)
EVAP CANISTER
EVAP TEMP SENS AC ON SIG
EVAP VACUUM LEAK PUMP
EVAP VENT SOL SENSOR GND LOW MAF SIG HIGH MAF SIG TP SEN 2 SIG
EXTERIOR LIGHTS SYSTEM CRUISE CONTROL SYSTEM
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
IGN FAIL SAFE
IGN POSITIVE VOL CRANK SIG
IGNITION COIL 1
IGNITION COIL 3 IGNITION COIL 2
IGNITION COIL 4 (ON LEFT SIDE OF CYLINDER HEAD)
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
NOISE FILTER (IN INSTRUMENT PANEL FUSE BLOCK)
OVERDRIVE SWITCH
PLUG SPARK
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
SPARK PLUG
STARTING/CHARGING SYSTEM
VSS IN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l vin 8, fwd (3 of 3) -> EVAP VENT SOL SENSOR GND LOW MAF SIG HIGH MAF SIG TP SEN 2 SIG
