Pontiac Vibe I facelift (2002-2008) cd changer instrument panel cluster Wiring diagram
This page shows the only wiring diagram for the component.cd changer instrument panel cluster, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cd changer instrument panel cluster (1 of 1)
AIR PUMP FUSE
AIR PUMP RELAY (1.8L (VIN L))
ALT FUSE
ALT-S FUSE
AM 2 FUSE
AMP FUSE
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
CD CHANGER INSTRUMENT PANEL CLUSTER
DIGITAL RADIO RECEIVER
DOME FUSE
EFI FUSE
EFI RELAY
ETC S FUSE
FLASHER RELAY
FROM HEAD MAIN FUSE (DIAGRAM 1 OF 4)
FRONT DOME LAMP SUNROOF SWITCH
FUSIBLE LINK
GENERATOR
GRN WIRE
HAZARD FUSE
HEAD MAIN FUSE
HEAD RELAY
HORN FUSE
HORN RELAY
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
KEYLESS ENTRY MODULE MAP LAMP
LEFT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
MAIN FUSE
MAYDAY ONSTAR FUSE
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL MODULE (PCM) (1.8L (VIN 8), FWD)
RADIO
RADIO, AMPLIFIER
REAR DOME LAMP
RED WIRE
ST RELAY
STARTER
TO ABS 2 FUSE (DIAGRAM 2 OF 4)
TO HORN FUSE (DIAGRAM 1 OF 4)
TO IGNITION SWITCH (DIAGRAM 4 OF 4)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, MOUNTED TO INNER FENDER)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
VEHICLE INTERFACE UNIT (VIU)
W/ SUNROOF
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> CD CHANGER INSTRUMENT PANEL CLUSTER
