Pontiac Vibe I facelift (2002-2008) bare drain audio common ground wiring diagram
This page shows the only wiring diagram for the component.bare drain audio common ground, which is found in the car Pontiac Vibe I facelift (2002-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
bare drain audio common ground wiring diagram (1 of 1)
AMPLIFIER ANTENNA
ANTENNA
AUDIO COMMON
BARE
BARE DRAIN AUDIO COMMON GROUND
BATTERY
BATTERY SERIAL DATA
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
DIGITAL RADIO RECEIVER
HOT AT ALL TIMES DOME FUSE
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
NCA WIRE
ORG/ WIRE
RADIO
RED WIRE
SERIAL DATA
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, MOUNTED TO INNER FENDER)
WHT WIRE
Go to component -> Satellite radio circuit -> BARE DRAIN AUDIO COMMON GROUND
