Pontiac Vibe I facelift (2002-2008) 28 19 28 19 28 19 evap temp sens gnd ect input Wiring diagram

1.8L (VIN L) 1.8L (VIN L) AWD 1.8L (VIN 8) FWD 28 19 28 19 28 19 EVAP TEMP SENS GND ECT INPUT A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C FRESH RECIRCULATION SWITCH A/C FUSE A/C LED A/C ON SIG A/C REQUEST CTRL A/C REQUEST FEED A/C REQUEST SIG A/C SW FEED CKT BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLOWER MOTOR (AT LOWER RIGHT SIDE OF HVAC) BLOWER RESISTOR (AT MIDDLE OF HVAC) BLOWER SWITCH BLU/WHT WIRE BRN WIRE CLUTCH RLY CTRL DEFOGGER MODE SWITCH A/C RESISTOR (BEHIND RIGHT SIDE OF DASH) EVAP TEMP SENS IN FAN 1 RLY CTRL FAN 2 RLY CTRL FRESH POSITION FRESH/ RECIRCULATION AIR INLET ACTUATOR GAUGE FUSE GRN WIRE GRN/WHT WIRE HEADLIGHTS SYSTEM HEATER FUSE HOT AT ALL TIMES HOT IN ON OR START IGN ILLUM LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE OFF LOW POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH) RECIR POSITION RED WIRE RED/WHT WIRE RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH) RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH) HEATER RELAY SOLID STATE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT, MOUNTED TO INNER FENDER) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
