Car Wiring Diagrams for Charging circuit for Pontiac Vibe I (2002-2004)

ALT FUSE ALT-S FUSE MAIN FUSE BATTERY BLK WIRE BLU WIRE CHARGE IND ENGINE CONTROLS SYSTEM (FUEL INJECTORS) FUSE FUSIBLE LINK (2-GA GENERATOR GRN WIRE HOT IN RUN OR START IGNITION SWITCH INSTRUMENT PANEL CLUSTER INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT) NCA WIRE OFF ORG/ WIRE RED WIRE RIGHT INSTRUMENT PANEL JUNCTION BLOCK RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH) RUN WIRE SP 107 (IN ENG ACC HARN, NEAR PCM) STARTING CIRCUIT UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT, MOUNTED TO INNER FENDER) WHT WIRE YEL WIRE
