Car Wiring Diagrams for Power door locks circuit for Pontiac Vibe I (2002-2004)

ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE FLASHER RELAY (IN UNDERHOOD FUSE BLOCK) GLASS HATCH ACTUATOR SWITCH GRN WIRE HAZARD SWITCH HEADLIGHTS, ANTI-THEFT SYSTEMS IGNITION KEY ALARM SWITCH INSTRUMENT CLUSTER SYSTEM LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT DOOR LOCK SWITCH LEFT INSTRUMENT PANEL JUNCTION BLOCK MULTIFUNCTION ALARM MODULE RED WIRE RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT DOOR LOCK SWITCH RIGHT INSTRUMENT PANEL JUNCTION BLOCK TURN SIGNAL/ HEADLAMP SWITCH WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE

5 4 3 2 1 BATTERY ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE DIODE DOOR FUSE GAUGE FUSE GLASS HATCH ACTUATOR, COURTESY SWITCH GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER SYSTEM INSTRUMENT PANEL CLUSTER INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT) LEFT FRONT COURTESY SWITCH LEFT INSTRUMENT PANEL JUNCTION BLOCK LEFT REAR COURTESY SWITCH LEFT REAR DOOR LOCK ACTUATOR MULTIFUNCTION ALARM MODULE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) PPL PPL/WHT WIRE PROGRAM SIG LK/UNLK SIG GROUND RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE REMOTE CONTROL DOOR LOCK RECEIVER (AT RIGHT REAR OF VEHICLE, BEHIND QUARTER GLAS RIGHT FRONT COURTESY SWITCH RIGHT REAR COURTESY SWITCH RIGHT REAR DOOR LOCK ACTUATOR TAILGATE DOOR LOCK ACTUATOR UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) DOME FUSE WHT WIRE WHT/BLK WIRE WIPER/ WASHER SYSTEM YEL WIRE
