Courtesy lamps circuit for Pontiac Vibe I (2002-2004)
Courtesy lamps circuit
BLK WIRE
BLU WIRE
DIODE
DOME FUSE
FRONT DOME LAMP
GLASS HATCH COURTESY SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL LAMP DIMMER
LEFT FRONT COURTESY SWITCH
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LEFT REAR COURTESY SWITCH
MAP LAMP (W/O SUNROOF)
MULTIFUNCTION ALARM MODULE
POWER TOPS SYSTEM
REAR DOME LAMP
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT COURTESY SWITCH
RIGHT REAR COURTESY SWITCH
SUNROOF SWITCH ASSEMBLY
TAILGATE COURTESY SWITCH
THEFT DETERRENT MODULE (OPTIONAL) (BEHIND RIGHT SIDE OF DASH)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ POWER DOOR LOCKS
W/O POWER DOOR LOCKS
WHT WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
