Pontiac Vibe I (2002-2004) w/keyless entry w/o keyless entry Wiring diagram
This page shows the only wiring diagram for the component.w/keyless entry w/o keyless entry, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/keyless entry w/o keyless entry (1 of 1)
BLK WIRE
BLK/WHT WIRE
GRN/YEL WIRE
HORN
HORN RELAY
HORN SWITCH (AT STEERING COLUMN)
HOT AT ALL TIMES HORN FUSE
JUNCTION BLOCK (LEFT SIDE OF DASH)
MULTIFUNCTION ALARM MODULE (BEHIND LEFT SIDE OF DASH)
THEFT DETERRENT MODULE (BEHIND RIGHT SIDE OF DASH)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
W/KEYLESS ENTRY W/O KEYLESS ENTRY
Go to component -> Horn circuit -> W/KEYLESS ENTRY W/O KEYLESS ENTRY
