Pontiac Vibe I (2002-2004) vss in Wiring diagrams
This page contains all the electrical diagrams for the component. vss in, in which he is found in the car Pontiac Vibe I (2002-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram vss in (1 of 2)
6 10 (FWD) (AWD)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE PRESSURE MODULATOR VALVE (AT RIGHT FRONT SIDE OF ENG COMPT)
CRUISE
CRUISE CONTROL RELEASE SWITCH (M/T) (ON CLUTCH PEDAL SUPPORT BRACKET)
CRUISE CONTROL SERVO (AT LEFT REAR SIDE OF ENG COMPT)
CRUISE CONTROL SWITCH
CRUISE IND
CRUISE INTERRUPT COAST + CLUTCH CTRL
DATA LINK CNNECTOR
ECU-IG FUSE
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
GAUGE FUSE
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGN BRAKE SIG PNP SW SIG CRUISE IND CTRL
IGNITION SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LEFT OF STEERING COLUMN, BEHIND STORAGE COMPT)
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LOCK
PARK/ NEUTRAL POSITION SWITCH (ON FRONT OF TRANSAXLE)
PNK/BLK WIRE
PPL/WHT WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RESUME/ ACCEL
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RUN WIRE
SERIAL DATA CRUISE ON/OFF VSS IN IDLE SIG OVERDRIVE SIG ACC + GND
SET/ COAST
SHIFT LOCK CONTROL MDULE (ATTACTED TO RIGHT SIDE OF SHIFT LEVER)
SP 107 (IN ENG HARN, NEAR PCM)
SP 108 (IN ENG ACC HARN, NEAR PCM)
SP 200 (UNDER LEFT SIDE OF DASH)
STOP FUSE
STOP LAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
TRANSMISSION CONNECTOR
VSS IN
WHT WIRE
WHT/BLK WIRE
Go to component -> Cruise control circuit -> VSS IN
Wiring diagram vss in (2 of 2)
2 3 BRAID BRAID
A/C EVAPORATOR TEMPERATURE SENSOR
A/C SYSTEM
AC REQUEST EVAP TEMP SENS AC ON SIG
AUX IAC SOL
AUXILIARY INTAKE AIR SOLENOID VALVE (FRONT OF AIR CLEANER ASSEMBLY)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE SW
BRN WIRE
CAMSHAFT POSITION SENSOR (LEFT REAR OF ENGINE)
CMP/CKP GND
CRANKSHAFT POSITION SENSOR (BOTTOM FRONT OF ENGINE)
ECT OUT
ECT SENS IN IAT SENS IN TP SENS IN
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
EVAP CANISTER VENT SOLENOID VALVE (NEXT TO AIR CLEANER)
FUEL INJECTORS
FUEL TANK PRESSURE SENSOR (TOP OF FUEL TANK)
GRN/WHT WIRE
GRY WIRE
IGN FAIL SAFE RAOC VALVE HI RAOC VALVE LO CMP SENS IN CKP SENS IN SENSOR GND
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
LT GRN WIRE
PNK/BLK WIRE
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
PPL/WHT WIRE
RED/BLU WIRE
THROTTLE POSITION SENSOR (REAR OF THROTTLE BODY)
VSS IN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8l vin l (3 of 3) -> VSS IN
