Pontiac Vibe I (2002-2004) turn signal/ headlamp switch center console power outlet Wiring diagram
This page shows the only wiring diagram for the component.turn signal/ headlamp switch center console power outlet, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn signal/ headlamp switch center console power outlet (1 of 1)
ACCESSORY POWER CONTROL MODULE
BLK WIRE
BLOWER MOTOR RESISTOR
BLOWER SWITCH MOTOR
CD CHANGER (IF EQUIPPED)
CRUISE CONTROL MODULE
CRUISE CONTROL SERVO
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR
DAYTIME RUNNING LAMPS CONTROL MODULE
FRONT CIGAR LIGHTER
GLASS HATCH ACTUATOR SWITCH
IGNITION KEY ALARM SWITCH
IGNITION SWITCH
INFATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER INSTRUMENT PANEL LAMP DIMMER
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL FUSE BLOCK FLASHER RELAY
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT POWER WINDOW/DOOR LOCK SWITCH
LEFT INSTRUMENT PANEL JUNCTION BLOCK
MALFUNCTION ALARM MODULE
MAP LIGHT (W/O SUNROOF)
NOISE FILTER
P/W RELAY ST RELAY
POWER MIRROR SWITCH
POWERTRAIN CONTROL MODULE
REAR DEFOGGER SWITCH AUDIO AMPLIFIER
RELAY
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR LOCK SWITCH
RIGHT INSTRUMENT PANEL JUNCTION BLOCK HEATER RELAY
SUNROOF MOTOR
SUNROOF SWITCH ASSEMBLY
TO RIGHT INSTRUMENT PANEL JUNCTION BLOCK (DIAGRAM 4 OF 4)
TURN SIGNAL/ HEADLAMP SWITCH
TURN SIGNAL/ HEADLAMP SWITCH CENTER CONSOLE POWER OUTLET
WHT WIRE
WHT/BLK WIRE
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (3 of 4) -> TURN SIGNAL/ HEADLAMP SWITCH CENTER CONSOLE POWER OUTLET
