Pontiac Vibe I (2002-2004) theft mod sig mic sig drain wire sensor gnd Wiring diagram

1 2 3 4 5 6 7 8 SUPPLY V 16 14 15 INSTRUMENT CLUSTER SYSTEM 4 3 BRAIDED WIRE BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRAIDED WIRE DOOR OPEN SIG DRL MODULE SIG ECU-B FUSE ECU-IG FUSE FLASHER RELAY (IN UNDERHOOD FUSE BLOCK) GLASS BREAKAGE SENSOR GRN WIRE GRN/YEL WIRE HAZARD SWITCH HEADLIGHTS SYSTEM HORN CNTRL HDLMPS CNTRL HORNS SYSTEM HOT AT ALL TIMES HOT IN RUN OR START IGNITION KEY ALARM SWITCH INSTRUMENT PANEL CLUSTER INSTRUMENT PANEL LAMP DIMMER LEFT INSTRUMENT PANEL JUNCTION BLOCK LF DL KEY CYL RF DL KEY CYL LF DL LK SIG LF DL UNLK SIG RF DL UNLK SIG COURT LMP SIG MICROPHONE MULTIFUNCTION ALARM MODULE PRK LMP CNTRL I/P DIM CNTRL SUPPLY V GLASS BRK SENS IG SW SIG GND RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT INSTRUMENT PANEL JUNCTION BLOCK SEC IND V SEC SET SIG GROUND SECURITY INDICATOR START CUT RLY STARTING/ CHARGING SYSTEM SUPPLY V THEFT DETERRENT MODULE (BEHIND RIGHT SIDE OF DASH) THEFT MOD SIG MIC SIG DRAIN WIRE SENSOR GND TURN SIGNAL/ HEADLAMP SWITCH WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
