Pontiac Vibe I (2002-2004) tailgate actuator/ courtesy lamp switch rear hatch glass connector Wiring diagram
This page shows the only wiring diagram for the component.tailgate actuator/ courtesy lamp switch rear hatch glass connector, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate actuator/ courtesy lamp switch rear hatch glass connector (1 of 1)
BLK WIRE
BRN WIRE
CENTER HIGH MOUNT STOP LAMP
FUEL SENDER ASSEMBLY
GLASS HATCH ACTUATOR/COURTESY LAMP SWITCH
IDLE AIR CONTROL VALVE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KEYLESS ENTRY MODULE
LEFT BACKUP LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR TURN LAMP
LEFT TAIL/ STOP LAMP
NOISE FILTER
POWERTRAIN CONTROL MODULE
RADIO
REAR DEFOGGER NOISE FILTER
RIGHT LICENSE PLATE LAMP
RIGHT REAR TURN LAMP
RIGHT TAIL/ STOP LAMP RIGHT BACKUP LAMP
TAILGATE ACTUATOR/ COURTESY LAMP SWITCH REAR HATCH GLASS CONNECTOR
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 4) -> TAILGATE ACTUATOR/ COURTESY LAMP SWITCH REAR HATCH GLASS CONNECTOR
