Pontiac Vibe I (2002-2004) right rear solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.right rear solenoid valve, which is found in the car Pontiac Vibe I (2002-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear solenoid valve (1 of 1)
7 12 DATA LINK CONNECTOR (DLC)
ABS NO 1 FUSE ABS NO 2 FUSE
ABS PUMP MOTOR PMP MTR LO
ABS WARNING IND
ACCELEROMETER
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRAKE IND
BRAKE IND. CTRL
BRAKE PRESSURE MODULATOR VALVE (BPMV) (AT RIGHT FRONT SIDE OF ENG COMPT)
BRAKE SW IN VSS IN
CRUISE CONTROL MODULE
DECELERATION SENSOR (AWD ONLY) (UNDER DRIVER SEAT)
DRL MODULE LF WHEEL SPD LO
ECU-IG FUSE
FAN NO 1 RELAY
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SOLENOID VALVE
LEFT FRONT WHEEL SPEED SENSOR RIGHT FRONT WHEEL SPEED SENSOR
LEFT INSTRUMENT PANEL JUNCTION BLOCK
LEFT REAR SOLENOID VALVE
LEFT REAR WHEEL SPEED SENSOR
OFF
ORG/ WIRE
PMP MTR HI
PNK (UNDER LEFT SIDE OF DASH) WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT SOLENOID VALVE SOLENOID VALVE CONTROL SIGNALS
RIGHT INSTRUMENT PANEL JUNCTION BLOCK (BEHIND RIGHT SIDE OF DASH)
RIGHT REAR SOLENOID VALVE
RIGHT REAR WHEEL SPEED SENSOR
RR WHEEL SPD HI LR WHEEL SPD LO LR WHEEL SPD HI
RUN WIRE
SOLENOID GND BATT
SP 200 (UNDER LEFT SIDE OF DASH)
SP 201 (BEHIND RIGHT BODY HINGE PILLAR TRIM PANEL)
STOP FUSE
STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit -> RIGHT REAR SOLENOID VALVE
